1-1/2" Paired Line Targets (708)

SKU
708 Series Paired Line Targets
Overview
Ships in 2 Weeks

Plexiglas circular target may be backlit

The 708 paired line target is circular white plexiglas, with two paired lines that do not cross each other (a white cross outlined with black lines in each corner). These targets are translucent and may be backlit for additional visibility in low-light applications. Backlighting this target when used as the far target in a line of bore targets gives a great diffuse backlight for the other targets in the line. They are extremely similar to our 707 series, except that the 708 has a diameter of 1½" (38.1 mm). These targets have holes drilled through on the target's diameter for mounting and to facilitate target removal from tight spots.

The 708 is available in a variety of target pattern spacings as presented in the chart below. The line spacing is engraved at the top of the target (in inch units). We have information to help you choose the proper target line spacing in the knowledgebase. We also have other similar targets here.

Model Target Spacing
708-5 0.005" (0.13 mm)
708-10 0.010" (0.25 mm)
708-15 0.015" (0.38 mm)
708-20 0.020" (0.51 mm)
708-25 0.025" (0.64 mm)
708-30 0.030" (0.76 mm)
708-40 0.040" (1.01 mm)
708-50 0.050" (1.27 mm)
Specifications
Diameter in 1.4998 – 1.4993
Diameter mm 38.095 – 38.082
Finish None
Max Operating Temperature 190° F (87° C)
Mounting Holes 0.1285″ (3.3 mm) drilled through on 1.250″ (31.75 mm) between centers
Pattern Centered with respect to the diameter within 0.001" (0.025 mm), T.I.R.
Target Thickness Nominally 3/8″, actual thickness may vary due to nature of material
